Description
The Cloud MA80FT is a compact and highly versatile 80W single-zone commercial mixer amplifier, designed for seamless integration into professional audio installations. Combining flexible input options, 100V line capability, and installer-focused features, it provides a complete solution for background music and paging in a wide range of environments.
Engineered as part of Cloud’s trusted MA Series, the MA80FT is built to deliver reliable performance in decentralised systems, making it ideal for installations where equipment needs to be discreetly located close to the listening area.
Compact Amplification for Distributed Audio Systems
The MA80FT delivers 80W of mono output, supporting both low impedance (4Ω) and high impedance 70V/100V line speaker systems via rear panel configuration.
This flexibility allows it to be used in:
- Ceiling speaker systems in retail and hospitality
- Wall-mounted speaker installations in offices
- Distributed audio systems in education environments
- Localised AV setups for meeting rooms and digital signage
Its ability to support both system types makes it highly adaptable for new installations and upgrades.
Designed for Discreet, Decentralised Installation
Unlike traditional rack-mounted amplifiers, the MA80FT is designed to be installed close to the zone it serves. Its compact form factor allows it to be mounted:
- In ceiling voids
- Behind displays or projectors
- Inside cupboards or equipment enclosures
- Adjacent to speaker zones
This decentralised approach reduces cable runs and simplifies installation, particularly in retrofit projects.
Flexible Input Options for Commercial Use
The MA80FT provides multiple input options to support a variety of audio sources:
- Two stereo line inputs (summed to mono)
- Balanced microphone input with EQ and gain control
- 100V line input for integration with existing systems
- Facility port for remote input modules
This enables integration with:
- Media players and streaming devices
- Paging microphones
- External audio systems
- Remote wall plates such as LM-2 or Bluetooth modules
The result is a highly flexible system that can be tailored to specific venue requirements.
Facility Port for Remote Audio Integration
A key feature of the MA80FT is its built-in facility port, allowing direct connection of Cloud remote input modules such as LM-2 or Bluetooth input plates.
This enables:
- Local audio input within a zone
- Simplified wiring using CAT5/6
- Enhanced user control in commercial environments
This makes it particularly effective in venues where users need direct access to audio inputs without interacting with central equipment.
Paging and Priority Functionality
The MA80FT includes a dedicated microphone input with paging functionality, allowing announcements to override background music when required. Paging can be triggered via VOX or contact closure, ensuring flexibility across different system designs.
This is ideal for:
- Retail stores making announcements
- Hospitality venues communicating with staff or customers
- Education environments requiring voice priority
- Public spaces with paging requirements
Energy Efficient Operation
The MA80FT is ENERGY STAR certified and includes Auto Power Down (APD) functionality, reducing energy consumption when the system is idle.
This ensures:
- Lower operating costs
- Reduced environmental impact
- Efficient long-term operation
The unit automatically wakes when an audio signal is detected, ensuring seamless performance without manual intervention.
Built for Reliability and Protection
Designed for continuous use, the MA80FT includes comprehensive protection features:
- Thermal protection
- Overcurrent protection
- Dynamic clip protection
- Power-on delay to protect speakers
These features ensure long-term reliability in demanding commercial environments.
Ideal Applications
The Cloud MA80FT is widely used across commercial AV installations:
- Retail stores and shopping environments
- Bars, cafés, and restaurants
- Offices and corporate spaces
- Classrooms and education facilities
- Digital signage and display audio systems
- Museums and exhibition spaces
Its compact size and flexible connectivity make it particularly suited to single-zone systems.
