Description
The Cloud 24-240 is a professional 2-zone mixer amplifier designed for commercial audio installations requiring higher output, flexible zoning, and reliable system control. Delivering 2 x 240W of power, it provides a scalable and high-performance solution for hospitality, retail, corporate, and public address environments.
As part of the Cloud 24 Series, the 24-240 combines amplification, multi-source mixing, and paging functionality into a compact 1U rack-mounted unit, making it ideal for distributed audio systems across multiple areas.
Dual-Zone Audio Control with Independent Operation
The Cloud 24-240 features two independent zones, each with its own amplifier channel, allowing separate source selection and volume control across different areas.
This makes it ideal for:
- Restaurants with bar and dining areas
- Retail stores with multiple zones
- Offices and reception spaces
- Education and public buildings
Each zone operates independently, ensuring tailored audio performance throughout the venue.
High Output Power for Larger Installations
The amplifier delivers:
- 2 x 240W Class-D output per zone
This increased power capacity allows:
- More loudspeakers per zone
- Higher volume levels for foreground audio
- Greater coverage across larger spaces
Compared to lower-powered alternatives, the 24-240 is suited to medium to large commercial installations.
Flexible Speaker Support (100V and Low Impedance)
The Cloud 24-240 supports:
- 4Ω / 8Ω low impedance speaker systems
- 70V / 100V line distributed systems
This flexibility allows installers to deploy the amplifier across a wide range of applications, from localised high-quality audio to large distributed speaker networks.
Multi-Source Input Configuration
The unit includes:
- 4 stereo line inputs (balanced and unbalanced)
- 1 microphone input with paging capability
This enables:
- Multiple music sources to be connected simultaneously
- Integration of microphones for announcements
- Centralised system control without external mixers
Each input can be routed and controlled per zone, ensuring flexible system design.
Paging and Priority Control
The microphone input supports analogue paging with priority override, automatically reducing background music when announcements are made.
This ensures:
- Clear speech intelligibility
- Seamless integration into paging systems
- Reliable communication in commercial environments
An integrated chime function can also be triggered for announcements or access control integration.
Facility Port for Remote Input and Control
The Cloud 24-240 includes a Facility Port connection via RJ45, enabling integration with remote input plates such as LM-2 or Bluetooth modules.
This allows:
- Local audio input in different areas
- Wall-mounted volume and source control
- Simplified system expansion
This feature is particularly valuable for larger or multi-room installations.
Advanced System Integration and Control
Additional features include:
- RS232 interface for third-party control systems
- Remote music mute functionality
- Auxiliary and utility outputs for system expansion
These capabilities make the amplifier suitable for integration into more complex AV control systems.
Reliable Class-D Performance with Protection
The 24-240 uses transformer-less Class-D amplification with built-in protection, ensuring stable and efficient operation.
Protection features include:
- Thermal protection
- Short-circuit protection
- Output limiting
A variable-speed cooling system ensures reliable operation in continuous-use environments.
Compact 1U Rack Installation
Housed in a standard 1U 19-inch rack chassis, the Cloud 24-240 is designed for efficient installation in AV racks and equipment cabinets.
Its compact footprint allows high-performance audio control without excessive rack space.
Ideal Applications
The Cloud 24-240 is widely used in:
- Bars, restaurants, and hospitality venues
- Retail stores and shopping environments
- Corporate offices and conference spaces
- Education facilities
- Public address and multi-zone audio systems
Its higher output and dual-zone capability make it particularly suited to larger or more demanding installations.
